General Information

---

Manufacturer:Eaton Corporation
Manufacturer Part Number:ECO350UPS
Manufacturer Website Address:http://www.eaton.com
Brand Name:Tripp Lite by Eaton
Product Series:ECO
Product Model:ECO350UPS
Product Name:ECO350UPS 350VA Ultra-compact Desktop/Tower/Wall Mount UPS
Marketing Information:Ultra-high efficiency ECO Series UPS System saves energy by automatically powering off unused computer accessories when the computer is not in use. UPS system uses less electricity than conventional models. Design includes three battery-supported outlets for computer, monitor and one vital system peripheral, plus three additional surge suppression-only outlets for accessories not requiring battery support. Two of the surge-only outlets are designated Eco outlets that can be configured to automatically power off when the computer enters standby mode or is shutdown. USB port enables UPS configuration options and unattended system shutdown without data loss in the case of extended power failure. UPS system meets RoHS standards. 350VA/180-watt power handling ability supports entry-level PC systems for up to 12 minutes during power fail conditions.

Packaged Quantity:1 Each
Product Type:Standby UPS

Technical Information

---

Plug/Connector Type:NEMA 5-15P
Receptacle Type:NEMA 5-15R
Receptacle Detail:6 x NEMA 5-15R
Number of Surge-only Outlets:3
Overload Protection:Yes
Transfer Time:6 ms
Phase:Single Phase
Application/Usage:

• Retail
• Hospital
• Computer Peripheral

Power Description

---

Load Capacity (VA):350 VA
Load Capacity (Watt):210 W
Input Voltage:120 V AC
Output Voltage:

• 110 V AC
• 115 V AC
• 120 V AC

Output Frequency:60 Hz
Waveform Type:Pure Sine Wave
Surge Energy Rating:316 J

Management

---

Alarm:

• Battery Fault
• Overload
• Low Battery

Interfaces/Ports

---

USB:Yes
USB (HID Compliant) Port:Yes

Battery Information

---

DC System Voltage:12 V DC
Battery Characteristics:Valve-regulated
Battery Chemistry:Lead Acid
Backup/Run Time (Full Load):2 Minute
Backup/Run Time (Half Load):8 Minute
Typical Battery Recharge Time:6.50 Hour
Replaceable Battery:Yes

Environmental Conditions

---

Minimum Operating Temperature:32°F (0°C)
Maximum Operating Temperature:104°F (40°C)
Storage Temperature:5°F (-15°C) - 133°F (56.1°C)
Maximum Storage Elevation:6561 ft

Physical Characteristics

---

Color Family:Black
Product Color:Black
Height:4.1"
Width:4.3"
Depth:7.3"
Form Factor:Ultra-compact Desktop/Tower/Wall Mount
Weight (Approximate):5 lb

Miscellaneous

---

Package Contents:

ECO350UPS 350VA Ultra-compact Desktop/Tower/Wall Mount UPS

USB Cable

Owner's Manual

Certifications & Standards:

UL Listed Certification

Recycled:No
Assembly Required:No
Energy Star:Yes
Country of Origin:Vietnam
Environmentally Friendly:Yes
Energy Efficiency Certification:ENERGY STAR 2.0
Environmental Compliance:Restriction of Hazardous Substances (RoHS)

Warranty

---

Limited Warranty:3 Year
Additional Warranty Information:

• 2 year

• 100,000 connected equipment guarantee
